Stainless Steel Industrial Keyboard With Trackball IP67 Waterproof Grade Ball Volume 50mm

Name: Stainless Steel Industrial Keyboard With Trackball IP67 Waterproof Grade Ball Volume 50mm
Brand: guangzhi
Price: 1 USD

Brand Name : guangzhi

Model Number : GZ-D004033-001

Certification : FCC, CE, ROHS, ISO9001

Place of Origin : Shenzhen,China

MOQ : 1pcs

Price : To be quoted

Payment Terms : T/T, Paypal

Supply Ability : 100000pcs

Delivery Time : 10-20 work days

Packaging Details : Individual product package size:235*150*50mm, Carton Size:482*320*275;

Application : ATM, self-service equipment, game consoles, access control, medical equipment, military equipment, marine equipment, mine equipment, etc.

Connection : USB or PS2

Material : stainless steel

Sphere volume : 50mm

Interface type : USB, PS/2, wire, USB/PS/2

Contact Now

Waterproof IP67 stainless steel industrial computer mouse track ball, ball volume 50mm

Description Of Metal Numeric Keypad

Waterproof stainless steel keyboard, number key and two function keys, compact layout of keys, using 0.5mm long key stroke, the installation method is from inside to outside, the whole thickness is: 13.5mm (excluding the control board), using full waterproof silica gel design, stainless steel panel and laser engraved key design, the mold with precision and accuracy, beautiful and generous surface treatment.

Product P/N:GZ-D004033-001

Environmental adaptability:
1. Operating temperature: - 10 ℃ to + 50 ℃
2. Storage temperature: - 30 ℃ to + 80 ℃
3. Relative humidity: 30-95% (no condensation)
4. Atmospheric pressure: 50-110kpa
5. Salt spray test: 96 hours, iec60512-6
6. 40 ℃ high tide humidity test: 21 days, iec60512-6
7. High drying test at 85 ℃: 10 days, iec60512-6

ITEM		SPECIFICATION
Key	3 keys, quality brushed stainless steel
Key Travel	2.0 mm
Ball diameter	50mm
Key switch lifespan	more than 10 Mio actuations
Track ball lifespan	> 10 Mio revolutions
Actuation Force	0.6 N to 1.2 N
Dimension	160.0mm x 120.0mm x 63.0mm (L x W x H)

Electrical parameters:
1. Working voltage: DC + 5V + / - 5%
2. Working current: 10mA
3. Electromagnetic radiation: EN50081-1
4. Electromagnetic immunity: en50082-1
5. EMC standard: 89 / 336 / EEC en55022:1988 + a1:2003 en55024:1988 + A1:2001 + a2:2003
6. Expected service life: > 5 years

Reliability:

MTBF	>20000H
MTTR	<30min
